Ever had the issue of not having enough room to cook
or have seats outside but still under roof while caravanning ?
Problem solved – with our premium superior quality awning extension you no longer have to suffer
Extremely easy to fit using AFK (anti flap kit) with keder slide
Now you can bbq out of the rain/sun
Plenty of room for the family with its large 1900mm x1250mm roof area
Width at keder spline attachment – 1900mm
projection outwards – 1250mm
Privacy screen attached to let breeze in but offer practical privacy – shade screen is 1800mm drop
Tried – tested – modified over time – premium superior sunscreen
All 100% Australian made by CAMPING MATE, made to last – built to provide enjoyment while caravanning
*FRONT SHADE SCREEN is in GREY, roof is grey with grey sides
Shade screen Drop Length 1800mm
*NEW FEATURE OPTION ADDED roll up front shade option now included – 3 velcro 50mm strips sewn in to offer this
Please NOTE our porches can be used either end of the van, they are not specific to one end, if using at rear of van the badge will be on inside.
—————————————————————————————————————————————————
CAMPING MATE GUARANTEES THE QUALITY OF THIS PRODUCTS FOR A FULL 3 YEARS
We are so confident in the quality of this product that i offer a replacement warranty for a full 3 years from the time of purchase
Warranty does not cover misuse
*please note – 2 upright poles and 1 spreader pole is required for this setup – purchased easily thru any camping outlet
This uses our new GEN 2 Shade - commercial quality 300+gsm UV and heatset
Product Specifications
Package contains –
Awning extension with privacy screen
4x tie down straps 13inch long
Will fit either full van or poptop
Colour: dark grey/GREY binding
Material Specifications:
The construction in the awning extension offered here is second to none – with the features as follows –
Roof construction is – 460GSM UV Stabilised warp knit Polyester fabric – 1160N breaking force
Privacy screen area features Triple reinforced sides with a finished thickness including pvc cross binding of 5mm – this ensures the the sides will not curl
PVC cross binding width just over 22mm, offering great reinforcements on the sides and bottom – This pvc binding features a Weight of: 250gsm
LARGE reinforced points along bottom to ensure the wall is well secured using the included tie down straps – the Polyester reinforcement points offers GSM 460 and Tensile strength – 1160 N
Nominal shade up to 91% – heavy duty 200gsm – lets breeze through while keeping you cool
Sp4 eyelets – proven to be superior in this application – full stainless steel eyelet – 316 stainless, marine grade, strongest on market
Marine grade Stretch cord tie down straps with hooks on each end – 13inch length
Heavy Duty keder slide spline 7.5mm
Frequently Asked Questions
✔ Can these porches be used on either side of the van (front or rear)?
Yes — designed to be used on either side. If used at the rear, the badge will be on the inside.
✔ Do you offer other side porches (wider or longer)?
Yes — all products are made in Brisbane, so we can offer custom porches to suit your setup.
✔ Is the roof waterproof?
Yes — the roof on all our awnings is 100% waterproof and hail resistant.
✔ Do you offer different keder / sail track sizes?
Yes — available in 4mm, 6mm and 7.5mm to suit various setups.
✔ How does this awning attach to a caravan or camper?
Best installed using an anti-flap kit.
✔ Can I use a caravan-style awning on a hybrid caravan?
It depends on how your awning is mounted. Some hybrids are roof-mounted (pop-top), others fixed to the van — ensure you choose the correct type for your setup.
